> Capacity : R-201 Series  100ml ∼ 10Liter

 R-211 Series  300ml ∼ 10Liter
> Design Pressure : 5000psig
> Design Temp. : 500°C
> Materials : 316SS
> Sealing : PTFE & Metal Sealing
> Stand : Batch Type or Floor Type

> Capacity : R-202 Series  100ml ∼ 10Liter

 R-212 Series  300ml ∼ 10Liter
> Design Pressure : 220 psig
> Design Temp. : -30 ~ 250 °C
> Materials : 316SS (R-202 Series) / Glass (R-212 Series)
> Sealing : PTFE & Metal Sealing
> Stand : Batch Type or Floor Type

> Capacity : 5ml ∼ 2Liter
> Design Pressure : 1000 ∼6000psig
> Design Temp. : 800°C
> Materials : 316SS & Hastel. C-276
> Liquid Viscosity : 40cp Max (at pump after heating)
> Stand : Floor Type

> Capacity : 50ml ∼ 10Liter
> Design Pressure : 10000psig
> Design Temp. : 500°C
> Materials : 316SS & Hastel. C-276
> Stand : Floor Type

> Reactor can be controlled by software.
> Indicating : Temperature, Pressure, Mass Flow, Motor Speed
> Control : Motor Flow, Temperature, Heater Power, End Time, Motor Speed
> Emergency Button
> Saving Data

> Capacity : 10 ∼ 40 Liter
> Temp. Range : -70°C ∼ 180℃
> Stability : ±0.01 ∼ ±0.02℃

> Torque : 16 ∼ 120 in-lbs
> Design Press. : 5000psig at 500°C
> Impeller Shaft Dia. : 10 ∼ 25mm
> Materials : Samarium Cobalt Magnets
> Carbon Graphite Sleeve Bearing

>Flow Rate: 0.003-5.0 cc/min、0.01-10.0 cc/min、0.01-20.0 cc/min、

                    0.02-40.0 cc/min、0.04-80.0 cc/min

>Maximun Pressure: 6000psi

>Disply: Digital LCD

>Remote Control: RS-232, 0-5VDC, 4-20mA
>Tubing Connections : Inlet1/4"  , Outlet1/8" or 1/16"
